Shelf support “Kintai”

PRODUCT INFORMATION

• For shelf minimum 16 mm thick (panel or wood).
• The particular shape of the components guarantees the locking of the shelf and, therefore, the transportation of the furniture with the shelves already assembled.
• It consists of a plastic sleeve with a spring inside, which clicks the pin in and out. As for the installation,also the dis-installation does not require the use of any tool, as it is simply carried out by sliding the clip backwards.
• In accordance with the European regulations UNI EN 14749/05.
• Recommended load capacity (Width x Length, mm – Max. shelves Weight) 300×600 mm – 32; 300×800 – 28; 450×600 mm – 30; 450×800 mm – 25. Easily variable shelf height.
• Diameter, mm : 5

ORDER INFORMATION
