Cinetto PS48 System for Wardrobes with Overlapping Sliding Doors
PRODUCT INFORMATION
Cinetto PS48 System for Wardrobes with Overlapping Sliding Doors
- 80 kg for one panel. Panel thickness from 18 mm up to 53 mm.
- The upper and lower rollers with bearings.
- Doors adjustment from front.
- Upper rail is “C” shape, protecting against buckling.
- Minimum gap between floors only 25 mm or 17 mm ( Upon request ).
- Minimum gap between ceilings only 40 mm.
- Minimum doors width if fixing soft-close system – 400 mm.
- Comfortable adjustment +/- 3 mm.
- Special door brackets construction do not let to bend and to contact doors.
- Patented wheels system lets fast fastened door and protects against their self opening.
- Softspace soft-close system is fixing to upper rail that’s why it is not visible.
MOUNTING INSTRUCTIONS:
Download mounting instructions
ORDER INFORMATION
£1.00 – £136.61
All Variations
| SKU | Price | Description | Quantity | Add to Cart |
|---|---|---|---|---|
| CI.PR48704A.610 | £136.61 (ex. VAT) £163.93 (inc. VAT) | Reinforced upper rail; L mm 6100 | ||
| CI.PR48704A.302 | £68.31 (ex. VAT) £81.97 (inc. VAT) | Reinforced upper rail; L mm 3020 | ||
| CI.PR48704A.152 | £34.15 (ex. VAT) £40.98 (inc. VAT) | Reinforced upper rail; L mm 1523 | ||
| CI.PR10725A.610| | £101.43 (ex. VAT) £121.71 (inc. VAT) | Bottom rail; L mm 6100 | ||
| CI.PR10725A.302| | £50.72 (ex. VAT) £60.86 (inc. VAT) | Bottom rail; L mm 3020 | ||
| CI.PR10725A.152| | £25.00 (ex. VAT) £30.00 (inc. VAT) | Bottom rail; L mm 1523 | ||
| CI.PS48AP2E01 | £50.58 (ex. VAT) £60.69 (inc. VAT) | Set of wheels for inside panel | ||
| CI.PS48AP2E1801 | £66.98 (ex. VAT) £80.37 (inc. VAT) | Set of wheels for external panel when inside panel is 18 mm thick | ||
| CI.PS48AP2E2301 | £60.93 (ex. VAT) £73.11 (inc. VAT) | Set of wheels for external panel when inside panel is 23 mm thick | ||
| CI.PS48AP2E2801 | £61.55 (ex. VAT) £73.86 (inc. VAT) | Set of wheels for external panel when inside panel is 28 mm thick | ||
| CI.PS48AP2E3301 | £62.15 (ex. VAT) £74.58 (inc. VAT) | Set of wheels for external panel when inside panel is 33 mm thick | ||
| CI.PS48DU4008 | £13.50 (ex. VAT) £16.20 (inc. VAT) | SoftSpace® soft-close system for opening and closing; 15 kg | ||
| CI.PS48DU4004 | £13.50 (ex. VAT) £16.20 (inc. VAT) | SoftSpace® soft-close system for opening and closing; 30 kg | ||
| CI.PS48DU4001 | £13.50 (ex. VAT) £16.20 (inc. VAT) | SoftSpace® soft-close system for opening and closing; 50 kg | ||
| CI.PS48DU4002 | £13.50 (ex. VAT) £16.20 (inc. VAT) | SoftSpace® soft-close system for opening and closing; 80 kg | ||
| CI.PS48AD8L02 | £3.55 (ex. VAT) £4.26 (inc. VAT) | Right-side soft brake promoter is attached to the brackets | ||
| CI.PS48AS8L02 | £3.53 (ex. VAT) £4.24 (inc. VAT) | Left-side soft brake promoter is attached to the brackets | ||
| CI.PS48SM8B01 | £2.08 (ex. VAT) £2.49 (inc. VAT) | End position brake when mounting embossed handle (for the protection of the handle; the door can not pass) | ||
| CI.PS48KF8B01 | £6.33 (ex. VAT) £7.60 (inc. VAT) | End position brake with adjustable handle (in set elements for stopping one doors to two sides) | ||
| CI.PS48FI8B01 | £1.00 (ex. VAT) £1.20 (inc. VAT) | End position brake installing to bottom rail | ||
| CI.PS48KD308B | £74.63 (ex. VAT) £89.55 (inc. VAT) | SoftSpace® soft-close system for central door; 30 kg | ||
| CI.PS48KD508B | £74.63 (ex. VAT) £89.55 (inc. VAT) | SoftSpace® soft-close system for central door; 50 kg | ||
| CI.CN01000224 | £1.57 (ex. VAT) £1.88 (inc. VAT) | Upper rail fixing element; black color |
