TAGADA DESK BUNK BED

PRODUCT INFORMATION

SINGLE BUNK BED SYSTEM FOR USE IN WARDROBES AT LEAST 330 mm DEEP. THE DOOR IS PLAIN AND DESIGNED TO ACCOMMODATE THE DESK TOP. THE TOP BED BASE IS SELF-SUPPORTING, NOT LINKED TO THE BOTTOM ONE AND FEATURES A HANDY SYSTEM FOR EASY BED MAKING. THE OPENING AND CLOSING MECHANISM IS CONTROLLED BY SUITABLE GAS SPRINGS. GUARD RAILS ARE SECURED TO THE SELF-SUPPORTING LADDER FOR TOTALLY SAFE ACCESS. SAFETY LOCK IS COMPULSORY.

• Bed base and matters: 900×2000
• Max. mattress H: 160.
• Mattress Kg: 15-20kg
• Total H of structure:2190.
• Width of structure: 2090.
• Height of structure: 2065.
• Min. Depth of structure: 330.
• Min. thickness of side: 22.
• Max. thickness of door: 18.
• Door weight approximate: 28 kg (±4%)
• Desk weight approximate: 20,5 kg (±4%)

Set is composed of:

• no.01 UPPER SLATTED BED BASE TAGADA’, (tube 50×25 mms) side opening, with opening mechanism kit, belts to hold the mattress in place, crossbar as panel stopper;
• no.01 LOWER SLATTED BED BASE PLAY DESK (tube 50×25) side opening, with opening mechanism kit, belts to hold the mattress in place; with door retaining brackets as panel stoppers;
• no. 01 KIT GUARD BARRIER and inclined ladder

NOTES
