PS65 Sliding Door System
PRODUCT INFORMATION
Cinetto PS65 Sliding Door System
- 60 kg for one door
- The system requires only the top rail.
- Wooden door thickness 40 mm (+ -1mm)
- Fillers available for doors made of profiles: 4/6 mm glass or 8 mm wooden panel
- The Softspace soft soft-close system is mounted on the top rail, making it invisible.
- Convenient vertical adjustment of mechanisms +/- 4,5 mm.
- Additional vertical upper rail adjustment +/- 5 mm if the rail is attached to the ceiling with extended pins).
- Fasteners on the top rail for camouflaged wooden panels when the
- Double top rail is fastened with extended pins.
- The set of details of the Pack system will allow connecting several doors to open one after the other like the principle of “telescope”.
NOTES
Download technical information
